Digital X-ray machine PCBs act as the core control hub, precisely managing high-voltage generators (up to 150kV) for X-ray emission, regulating mechanical movements of tubes, gantries and collimators, and processing analog-to-digital data from flat-panel detectors (FPDs) to produce high-resolution diagnostic digital images. These boards require ultra-robust designs—including reinforced insulation layers, high-voltage isolation structures and low-noise signal paths—to withstand intense electrical stress and ensure interference-free, accurate data acquisition. Backed by our professional manufacturing capabilities, we produce reliable PCB control systems, covering multilayer boards (up to 16 layers) with ENIG finish and precision SMT assembly, fully complying with stringent medical imaging standards (IEC 60601, FDA) for clinical application.
